Description
Complete Midnite Power and Growatt Hybrid Solar Kit | 8kW+ Solar Power, 10kW Output, 16kWh Energy Storage
KIT-GROWATT-02
Core Hardware
- Growatt SPH 10000TL-HU-US Hybrid Inverter (10 kW, 48 V)
• 98 % CEC efficiency, three MPPTs, UL 1741 SA & SB ready
• Seamless on/off-grid switching keeps critical loads alive during outages
• Wi-Fi/4G monitoring with Growatt Shine Cloud and EV-charging supportIntegrated ATS and Generator Port - MidNite Power MNPowerflo16 LiFePO4 Battery (16.1 kWh)
• 6,000-cycle life, built-in BMS and heater for cold climates
• Wall-mount, outdoor-rated NEMA 3R enclosure
• 15 Year Comprehensive Warranty - Protection & Balance of System
• 2x MNSPD600 surge arrestors (AC + PV)
• 1x IMO DC disconnect for safe array isolation
• 1x Pair of 4/0 AWG battery-to-inverter cables (pre-lugged, UL-listed)
• 2x 50 ft PV wire runs (10 AWG, red & black, MC4) for clean rooftop-to-combiner routing
Choose Your Premium Bifacial or TOPCon Module Set
- Canadian Solar 705W – 12 Panels / 8.5 kW
High-output, high-wattage panels for maximum production. - TaleSun 445W Black (N-Type) – 18 Panels / 8.0 kW
Sleek all-black look with lighter roof loading and excellent low-light response. - Canadian Solar 445W (Mono PERC) – 18 Panels / 8.0 kW
Proven, high-efficiency mono PERC performance in a classic workhorse panel.
Why this kit?
- Whole-home resilience – 10 kW continuous output and 16 kWh of storage keep HVAC, well pumps, and kitchen loads online when the grid fails.
- Future-proof architecture – Add a second MNPowerflo16 for 32 kWh or parallel another SPH inverter for 20 kW AC without rewiring.
- Installer-friendly – Color-coded MC4 leads, pre-terminated battery cables, and clip-on surge protectors slash rooftop and BOS labor.
- Code-compliant safety – Rapid shutdown-ready inverter, SPD600 lightning defense, and IMO disconnect meet NEC 2023 requirements.
- Smart savings – Use Growatt’s Time-of-Use scheduler to charge from solar or off-peak grid power and discharge during high-rate windows.
Bring industrial-grade power security and utility-sized savings to your home or small business with this turnkey kit—backed by Michigan-based technical support and the industry’s leading warranties.
