Among the newest offerings of Phono Solar, PS590M8GFH-24-TNH is part of the Draco Module series. These panels use state-of-the-art technology to achieve high efficiency and dependability. The solar cells of PS590M8GFH-24-TNH are half the size of those found in standard panels. Major advantages include reduced power consumption, extended life, and enhanced efficiency in low-light conditions. Not surprisingly, the efficiency of this module is quite high – 22.84%. And while conventional panels use only one side to absorb photons, bifacial modules employ both sides at the same time. Thanks to the technology, this model can be up to 30% more efficient. Phono Solar paid as much attention to durability as they did to performance. PS590M8GFH-24-TNH is guaranteed to retain at least 87.40% of output after 30 years. Product warranty for this panel lasts 15 years.
- 590 W power output
- 144 half-cut N-Type cells
- 22.84% efficiency
- 1500 V DC maximum system voltage
- MC4 connectors
- 15-year product warranty and 30-year linear performance warranty
More power and efficiency
An already high efficiency of 22.84% is further enhanced by N-Type cell technology. By adding a solid PID resistance and special glass lamination on top, the manufacturer ended up with an efficient and very durable model. Under standard test conditions, PS590M8GFH-24-TNH outputs 590 W of power.
Improved efficiency at high temperatures
Greater energy as temperature rises is a mark of a good temperature coefficient. Your panel’s efficiency will drop by just -0.29% for every 1.8°F increase over 77°F.
High-quality standards
Phono Solar’s stringent production requirements include various tests to guarantee high quality. The facilities are highly automated, allowing the manufacturer to maintain high standards while keeping warranty claims to a minimum.
Reliability and degradation resistance
Slow degradation over the next 30 years is guaranteed by Phono Solar. The performance will decrease no more than 1% during the first year and 0.4% annually thereafter. Your modules will retain at least 87.40% of their original performance after 30 years. This 590 W Phono Solar solar panel also comes with a generous 15-year product warranty.
Enhanced frame design
This model’s construction makes it perfect for both residential and business rooftops. Durability and strength are increased by using a strong, robust frame built from anodized aluminum alloy. A significant snow load of up to 5400 Pa may be supported by the model. The panel’s back can support 2400 Pa, assuring that even the strongest winds won’t damage your system.
Size
89.69″ x 44.65″ x 1.18″
Weight
70.55 lb
