Fortress Power EV6500-S 6500W Offgrid Split Phase Inverter

Description

AVAILABLE IN Nov 1ST 2025

Reliable, Flexible Power for Off-Grid and Backup Applications

The Fortress Power EV6500-S is a next-generation off-grid solar storage inverter built for reliability, scalability, and intelligent energy control. Designed to handle both split-phase and single-phase loads, it delivers up to 6,500W continuous output and 13,000W peak output, making it ideal for off-grid living, home backup, microgrids, and peak shaving.

Equipped with time-based charging and discharging, generator/grid hybrid input, and intelligent switching, the EV6500-S gives homeowners and installers ultimate flexibility in managing energy consumption and production. Its high-capacity solar charge controller (up to 140A) ensures efficient solar harvesting, while support for up to six parallel units allows expansion up to 39kW of output power.

Product Specifications

Fortress Power EV6500-S 6500W Offgrid Split Phase Inverter Product Specifications

GENERAL DATA
Weight 47.84 lbs (21.7 kg)
Operating Temperature 14 ºF – 131 ºF (-10 ºC – 55 ºC), >45 ºC derating
Protection Level IP20 (for indoor use only)
Noise <60db
Dimensions (W x D x H) 25.5 x 16.1 x 5.5 in (648 x 410 x 140 mm)
Cooling Mode Fan
INVERTER OUTPUT
Rated Output Power 6,500W
Maximum Peak Power 13,000 VA
Rated Output Voltage 120/240 VAC (Single/Split-Phase)*
Rated Frrequency 50/60Hz*
Output Wave Pure Sine Wave
Switching Time 10 ms (typical value)
Parallel Number 6
BATTERY PARAMETERS
Compatible Battery Type Lithium-ion battery / lead-acid battery / user- defined battery*
Rated Battery Voltage 48 Vdc
Voltage Range 40 Vdc-60 Vdc*
Maximum Grid/Generator Charge Current 80 A DC*
Maximum Battery Charge Current 140 A DC*
PV INPUT
MPPT Channel Number 2
Maximum Input Power 5,000W+5,000W
Maximum Input Short Circuit Current 18 / 18 A
Maximum Open Circuit Voltage 550 Vdc / 550Vdc
MPPT Operating Voltage Range 150 Vdc-450 Vdc
GRID / GENERATOR INPUT
Input Phase Voltage Range 65 VAC – 140 VAC
Grid Frequency Range 50/60 Hz
Bypass Overload Current 40A
COMMUNICATION
Built-in Interface RS485 / CAN / USB / dry contact*
External Module (Optional) Wi-Fi / GPRS*
EFFICIENCY
MPPT Tracking Efficiency 99.9%
Maximum Efficiency of Battery Inverter 93%
STANDARDS & CERTIFICATIONS
Safety Standards IEC62109-1, IEC62109-2, and UL1741
EMC EN61000-6-1, EN61000-6-3, and FCC 15 class B
RoHS Yes
